iF647 Anti-Human CD184 (CXCR4) Antibody

Product Details


CloneUlocuplumab
ApplicationFlow Cytometry
ReactivityHuman
FormatiF647
Target NameCD184, CXCR4
IsotypeHuman IgG4
Antibody TypeMonoclonal
Regulatory StatusRUO
FormulationPhosphate-buffered solution, pH 7.2, containing 0.09% sodium azide and 0.2% (w/v) BSA
Protein ConcentrationSupplied at a lot-specific concentration.
Storage&HandlingThe antibody solution should be stored undiluted between 2°C and 8°C, and protected from prolonged exposure to light. Do not freeze.
Recommended UsageFor flow cytometric staining, it is recommended to use 5 µL of this reagent per 0.5-1.0 million cells in a 100 µL volume. Optimal reagent performance should be determined by titration for each specific application. iF647 has an excitation max at 656 nm and an emission max at 670 nm.
Excitation LaserRed Laser (633 nm)
See All FormatsClone Ulocuplumab

Background Information


CD184, also known as CXCR4 (C-X-C chemokine receptor type 4), is a G protein-coupled receptor (GPCR) that plays a central role in cell migration, immune regulation, and development. It is expressed on a wide variety of cells, including hematopoietic stem and progenitor cells, lymphocytes, endothelial cells, and many types of cancer cells. CXCR4 primarily functions as a chemokine receptor that guides cell trafficking and positioning in response to chemotactic gradients, making it essential in immune surveillance, hematopoiesis, and organogenesis.

Structurally, CD184 is a typical seven-transmembrane GPCR composed of 352 amino acids with an extracellular N-terminal domain, seven hydrophobic transmembrane helices, three extracellular and intracellular loops, and a cytoplasmic C-terminal tail. The extracellular regions are responsible for ligand binding, while the intracellular domains interact with G proteins and β-arrestins to initiate downstream signaling cascades. The receptor is heavily glycosylated at the N-terminus, which contributes to ligand specificity and receptor stability. The cognate ligand for CD184 is CXCL12, also known as stromal cell–derived factor 1 (SDF-1). Binding of CXCL12 to CXCR4 triggers activation of multiple signaling pathways, including PI3K/AKT, MAPK/ERK, and calcium mobilization cascades, which collectively regulate migration, survival, and proliferation. The CXCL12-CXCR4 axis is critical for the homing of hematopoietic stem cells to the bone marrow and the migration of immune cells during inflammation and tissue repair.

CD184 has been implicated in numerous diseases, ranging from cancer to infectious and autoimmune disorders. In oncology, CXCR4 is frequently overexpressed in solid and hematologic malignancies, where it drives tumor growth, angiogenesis, metastasis, and resistance to therapy. The receptor also serves as a co-receptor for HIV-1 entry into T cells, enabling viral infection and progression to AIDS. Dysregulation of the CXCL12-CXCR4 axis is additionally associated with inflammatory diseases, such as rheumatoid arthritis and multiple sclerosis, due to aberrant immune cell recruitment.

Therapeutically, CXCR4 represents a major target in both cancer and regenerative medicine. Antagonists such as plerixafor (AMD3100) are used clinically to mobilize hematopoietic stem cells for transplantation. In cancer, CXCR4 inhibitors and monoclonal antibodies are under development to block metastasis and improve immunotherapy efficacy. Modulating this pathway continues to hold significant potential for controlling immune responses, enhancing stem cell therapies, and limiting disease progression across multiple clinical contexts.

Isotype Control


iF647 Human IgG4 isotype control (S228P)

Data Sheets


iF647 Anti-Human CD184 (CXCR4) Antibody TDS

Related Protocols


Flow Cytometry Protocol

Frequently Asked Questions


How do I determine the optimal antibody concentration/titer for my experiment?
We recommend titrating each new antibody lot on your own cell type and instrument, since optimal concentration depends on cell density, target expression level, and cytometer sensitivity. Suggested starting dilutions or test sizes (e.g., µg or µl per 10^6 cells) are provided on the product page as a starting reference point, not a fixed requirement.

Can these antibodies be used for intracellular or intranuclear staining, or only surface staining?
Intended use (surface, intracellular, or both) is specified per product, indicated under Application. The appropriate Related Protocol is linked for each product. If you need to detect both surface and intracellular markers in the same panel, confirm each antibody's compatibility with your fixation/permeabilization protocol before combining them.

What controls should I use alongside these antibodies?
Matched isotype controls (same host species, isotype, and conjugate) are available for most clones to help distinguish specific binding from background/non-specific staining and are linked on each product page. Unstained, single-color compensation, and fluorescence-minus-one (FMO) controls are also recommended, especially for multicolor panel design.

Can I combine InnoCyto Flow Cytometry antibodies into a multicolor panel?
Yes — antibodies across our catalog are designed to be panel-compatible, and conjugate options are offered specifically to support multiplexing. When building a panel, pair bright fluorophores with low-expression targets, avoid excessive spectral overlap, and confirm compensation is set up correctly for your specific fluorochrome combination. Use our Panel Builder to simplify the process.
